â– Input description:Â DC12-24V
â– Output description:
Input voltage: DC12-24V
USB-A port output: 5V/3A; 9V/3A; 12V/3A; 20V/3A(60W Max)
USB-C1 output: 5V/3A; 9V/3A; 12V/3A; 15V/3A; 20V/5A; 3.3~21V/3A(100W Max)
USB-C2 output: 5V/3A; 9V/3A; 12V/3A; 15V/3A; 20V/5A; 3.3~21V/3A(100W Max)
Note:
USB-A and USB-C2 ports can be used separately for fast charging, and at the same time, they can be used for high current of 5/3.5A.
USB-C1 has a boost and buck function, and the output is 100W Max when the input is 12V~24V
USB-C2 has a boost and buck function when used alone, and the output is 100W Max when the input is 12V~24V
Support agreement:
USB-A ports: QC2.0/QC3.0/AFC/FCP/SCP/BC1.2/PPLE2.4A/SAMSUNG5V2A
USB-C1 ports: QC2.0/QC3.0/QC4.0+/PD2.0/PD3.0/PPS/AFC/FCP/BC1.2/PPLE2.4A/SAMSUNG5V2A
USB-C2 ports: QC2.0/QC3.0/QC4.0+/PD2.0/PD3.0/PPS/AFC/FCP/BC1.2/APPLE2.4A/SAMSUNG5V2A
â– Output power:
When inputting 12V/24V voltage: USB-C1 port (100W)+USB-C2 port (100W), the total output power is 200W (Max)
USB-A port+USB-C2 port output total power 5/3.5A (Max)
USB-C2 port output power 100W (Max)
